6000-TSEN-01

6000 Series temperature sensor. Temperature Sensor for 6000 Series Purge system. Series: 6000 Series. System: Type X Purge ; Ex pxb Purge. Connection: . Power+ , - , sensors: . Power: + , - , sensors....

6000 Series temperature sensor. Temperature Sensor for 6000 Series Purge system. Series: 6000 Series. System: Type X Purge ; Ex pxb Purge. Connection: . Power+ , - , sensors: . Power: + , - , sensors. Rated voltage: 5.5 V DC. Rated current: max. 10 mA. Open loop voltage: 9.6 V. Distance: 3 m from 6000 control unit 3 m from 6000-TEMP-01. Ambient temperature: -20 ... 100 °C (-4 ... 212 °F). Storage temperature: -40 ... 100 °C (-40 ... 212 °F). Relative humidity: < 95 % non-condensing. Vibration resistance: 1 g , 10 ... 100 Hz , all axes. Impact resistance: 30 g, 11 ms, all axes. Housing material: Ryton BR III BL. Degree of protection: IP65. Cable: Gray PVC. Diameter5.03 mm2Wire gauge22 AWG: . Diameter: 5.03 mm2. Wire gauge: 22 AWG. Mass: approx. 110 g. Dimensions: 50 mm x 25 mm x 5 mm. Mounting: panel or DIN rail mounting. EU-type examination certificate: UL/Demko 07 ATEX 0705753X. UL approval: File no: E184741. cULusFile no: E184741: . cULus: File no: E184741. IECEx approval: IECEx UL 08.0003X

Brand	Pepperl Fuchs
Lifecycle status	active
