7500-MAN-BK-**-*

7500 Series manifold. Series: 7500. System: Type Z Purge ; Ex pzc Purge. Hazardous environment: gas or dust. Rated voltage: 230 VAC ±10%115 VAC ± 10%24 VDC ±10%. Power consumption: 230 VAC @ 1.8 W 115...

7500 Series manifold. Series: 7500. System: Type Z Purge ; Ex pzc Purge. Hazardous environment: gas or dust. Rated voltage: 230 VAC ±10%115 VAC ± 10%24 VDC ±10%. Power consumption: 230 VAC @ 1.8 W 115 VAC @ 9 W 24 VDC @ 9 W. Protective gas supply: instrument grade air or inert gas. Pressure requirement: T6 version: 0.2 bar (2.9 psi) to 4.0 bar (58 psi)T4 version: 0.2 bar (2.9 psi) to 16 bar (232 psi). Purge flow rate: Kv value water 3.8 m3/h. Connections: G1/2 (13 mm). Ambient temperature: -40 ... 55 °C (-40 ... 131 °F). Storage temperature: -40 ... 80 °C (-40 ... 176 °F). Connection type: Inlet/outlet size: G 1/2 (13 mm) Jet size: 3.0 mm and 4.5 mm size (included). Degree of protection: IP65. Material: Body: brassValve (intenal): brassSeal: NBR. EU-type examination certificate: . Marking II 2 G Ex mb IIC T4/T6 Gb [exsign] II 2 D Ex mb IIIC T130 °C / T80 °C Db Protection by encapsulation EPS 18 ATEX 1232 X: . Marking: II 2 G Ex mb IIC T4/T6 Gb [exsign] II 2 D Ex mb IIIC T130 °C / T80 °C Db Protection by encapsulation EPS 18 ATEX 1232 X. Certificate: CCC approvals. MarkingEx mb IIC T4/T5/T6 GbEx mbD 21 T80°C/T95°C/T130°C: . Marking: Ex mb IIC T4/T5/T6 GbEx mbD 21 T80°C/T95°C/T130°C. Directive conformity: . Directive 2014/34/EUEN IEC 60079-0:2018, EN IEC 60079-7:2015/A1:2018, EN 60079-18:2015/A1:2017, EN 60079-31:2014: . Directive 2014/34/EU: EN IEC 60079-0:2018, EN IEC 60079-7:2015/A1:2018, EN 60079-18:2015/A1:2017, EN 60079-31:2014. IECEx approval: IECEx EPS 18.0110XEx mb IIC T4/T6 GbEx mb IIIC T130 °C/T80 °C Db

Brand	Pepperl Fuchs
Lifecycle status	active
