921FS5-T-030-Z600

Inductive sensor. Extended temperature range, Switching function: Normally closed (NC), Output type: NAMUR, Installation: flush, Output type: 2-wire, Construction type: Other, Series: Cylindrical type...

Inductive sensor. Extended temperature range, Switching function: Normally closed (NC), Output type: NAMUR, Installation: flush, Output type: 2-wire, Construction type: Other, Series: Cylindrical type, Type of voltage: DC, Connection type: cable, Housing material: Stainless steel, Degree of protection: IP67, Material: FEP. Switching function: Normally closed (NC). Output type: NAMUR. Rated operating distance: 5 mm. Installation: flush. Assured operating distance: 0 ... 4.05 mm. Reduction factor rAl: 0.3. Reduction factor rCu: 0.2. Reduction factor r304: 0.7. Output type: 2-wire. Nominal voltage: 8.2 V (Ri approx. 1 kΩ). Switching frequency: 0 ... 500 Hz. Short-circuit protection: yes. Current consumption: . Measuring plate not detectedmin. 2.2 mAMeasuring plate detected≤ 1 mA: . Measuring plate not detected: min. 2.2 mA. Measuring plate detected: ≤ 1 mA. Standard conformity: . NAMUREN 60947-5-6:2000 IEC 60947-5-6:1999StandardsEN IEC 60947-5-2: . NAMUR: EN 60947-5-6:2000 IEC 60947-5-6:1999. Standards: EN IEC 60947-5-2. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -20 ... 110 °C (-4 ... 230 °F). Connection type: cable. Housing material: Stainless steel. Sensing face: Ceramic. Degree of protection: IP67. Cable: . Wire end ferrulesyesCable diameter4 mm ± 0.2 mmBending radius> 7.5 x cable diameterMaterialFEPColorwhiteNumber of cores2Core cross section0.355 mm2LengthL3 m: . Wire end ferrules: yes. Cable diameter: 4 mm ± 0.2 mm. Bending radius: > 7.5 x cable diameter. Material: FEP. Color: white. Number of cores: 2. Core cross section: 0.355 mm2. Length: 3 m. Dimensions: . Height30 mmDiameter20 mm: . Height: 30 mm. Diameter: 20 mm

Brand	Pepperl Fuchs
Lifecycle status	active
