ACX04-F99-I-V15

Acceleration sensor. 1 axis acceleration sensor, E1-Type approval, Analog output 4 mA ... 20 mA, Fixed evaluation limits , High shock resistance, Teachable zero point, Measuring range -2 <i>g</i> ......

Acceleration sensor. 1 axis acceleration sensor, E1-Type approval, Analog output 4 mA ... 20 mA, Fixed evaluation limits , High shock resistance, Teachable zero point, Measuring range -2 <i>g</i> ... +2 <i>g</i>, Increased noise immunity 100 V/m. Type: 1 axis acceleration sensor. Measuring range: -2 ... 2 g. Resolution: ≤ 5 mg. Repeat accuracy: ≤ ± 5 mg. MTTFd: 304 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Operation indicator: LED, green. Teach-in indicator: LED, yellow. Operating voltage: 10 ... 30 V DC. No-load supply current: ≤ 25 mA. Time delay before availability: ≤ 100 ms. Output type: 1 current output 4 ... 20 mA. Zero signal: 12 mA. Slope of output characteristic: 4 mA / g. Linearity error: ± 1.2 %. Load resistor: 0 ... 200 Ω at UB = 10 ... 18 V 0 ... 500 Ω at UB = 18 ... 30 V. Temperature influence: . Offset≤ ± 4 µA / KSlope≤ ± 20 µA / g: . Offset: ≤ ± 4 µA / K. Slope: ≤ ± 20 µA / g. Standard conformity: . Shock and impact resistance100 g according to DIN EN 60068-2-27StandardsEN 60947-5-2:2007 IEC 60947-5-2:2007: . Shock and impact resistance: 100 g according to DIN EN 60068-2-27. Standards: EN 60947-5-2:2007 IEC 60947-5-2:2007. UL approval: cULus Listed, Class 2 Power Source. CCC approval: CCC approval / marking not required for products rated ≤36 V. E1 Type approval: 10R-04. Ambient temperature: -40 ... 85 °C (-40 ... 185 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: 5-pin, M12 x 1 connector. Housing material: PA. Degree of protection: IP68 / IP69K. Mass: 240 g. Dimensions: . Height37 mmWidth45 mmLength65 mm: . Height: 37 mm. Width: 45 mm. Length: 65 mm

Brand	Pepperl Fuchs
Lifecycle status	active
