BRB60N-10S
Bearing box. Bearing box for offshore applications, shaft ∅12x20 with flat area, max. rotational speed 6000 min<sup>-1</sup> , High corrosion resistance, Compact and stable housing, High shaft load ca...
Bearing box. Bearing box for offshore applications, shaft ∅12x20 with flat area, max. rotational speed 6000 min<sup>-1</sup> , High corrosion resistance, Compact and stable housing, High shaft load capacity, Long service life due to minimal heat, even at high rotational speeds, Low starting torque, even at low temperatures. Degree of protection: DIN EN 60529, IP65 , IP66. Climatic testing: . Static climatic testingDIN EN 60068-2-78 , no moisture condensationCyclic climatic testingDIN EN 60068-2-30 55 °C, 6 cyclesSalt spray testDIN EN 60068-2-52 , 672 h: . Static climatic testing: DIN EN 60068-2-78 , no moisture condensation. Cyclic climatic testing: DIN EN 60068-2-30 55 °C, 6 cycles. Salt spray test: DIN EN 60068-2-52 , 672 h. Shock resistance: DIN EN 60068-2-27, 100 g, 3 ms. Vibration resistance: DIN EN 60068-2-6, 10 g, 10 ... 2000 Hz. Operating temperature: -40 ... 85 °C (-40 ... 185 °F). Storage temperature: -40 ... 95 °C (-40 ... 203 °F). Shaft dimensions: 10 x 20 mm with flat area 1 mm. Material: . Housingaluminum, coated, salt water resistantFlangealuminum, coated, salt water resistantShaftstainless steel 1.4404 / AISI 316L: . Housing: aluminum, coated, salt water resistant. Flange: aluminum, coated, salt water resistant. Shaft: stainless steel 1.4404 / AISI 316L. Mass: approx. 425 g. Rotational speed: max. 6000 min -1. Starting torque: ≤ 10 Ncm. Shaft load: . Axial200 NRadial350 N: . Axial: 200 N. Radial: 350 N. Life span: 3 x 109 @ 3000 min-1
| Brand | Pepperl Fuchs |
| Lifecycle status | active |
