ENA58PL-S***-CANopen redundant

Absolute rotary encoder. Solid shaft, Up to 30 bit overall resolution, Redundant CANopen Interface, Independent photoelectric and magnetic redundant sampling, Redundant connection option with 2 connec...

Absolute rotary encoder. Solid shaft, Up to 30 bit overall resolution, Redundant CANopen Interface, Independent photoelectric and magnetic redundant sampling, Redundant connection option with 2 connectors, Enclosure type: 58 mm, Type of shaft: Solid shaft, Interface: CANopen, Detection type: photoelectric and magnetic sampling, Interface type: CANopen. Detection type: photoelectric and magnetic sampling. Device type: Absolute rotary encoder. Linearity error: ≤ ± 0.1 °. UL File Number: E223176 "For use in NFPA 79 Applications only" , if UL marking is marked on the product.. Performance level (PL): Suitable for PL d; both channels of the encoder must be connected to a safety PLC and evaluated there.. Category: Suitable for cat. 3; both channels of the encoder must be connected to a safety PLC and evaluated there.. MTTF: 100 a at 40 °C (based on EN ISO 13849-1). Mission Time (TM): 10 a. Operating voltage: 10 ... 30 V DC (with galvanic isolation). Power consumption: ≤ 3.7 W. Time delay before availability: < 250 ms. Output code: binary code. Code course (counting direction): adjustable. Interface type: CANopen. Resolution: . Single turnup to 16 BitMultiturnup to 14 BitOverall resolutionup to 30 Bit: . Single turn: up to 16 Bit. Multiturn: up to 14 Bit. Overall resolution: up to 30 Bit. Transfer rate: min. 20 kBit/s , max. 1 MBit/s. Cycle time: ≥ 1 ms. Standard conformity: DSP 406. Connector: 1 plug M12 x 1, 5-pin, A-coded (with connection type BD) 1 plug M12 x 1, 5-pin, A-coded and 1 socket M12 x 1, 5-pin, A-coded (with connection type BN). Degree of protection: DIN EN 60529, IP65 or IP67. Climatic testing: DIN EN 60068-2, no moisture condensation. Emitted interference: EN 61000-6-4. Noise immunity: EN 61000-6-2. Shock resistance: DIN EN 60068-2-27, 100 g, 6 ms. Vibration resistance: DIN EN 60068-2-6, 20 g, 10 ... 1000 Hz. UL approval: cULus Listed, General Purpose, Class 2 Power Source , if UL marking is marked on the product.. Operating temperature: -40 ... 85 °C (-40 ... 185 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Relative humidity: 98 % , no moisture condensation. Material: . HousingAluminumFlangeAluminumShaftStainless steel 1.4305 / AISI 303: . Housing: Aluminum. Flange: Aluminum. Shaft: Stainless steel 1.4305 / AISI 303. Mass: approx. 320 g. Rotational speed: max. 3000 min -1. Moment of inertia: 30 gcm2. Starting torque: < 5 Ncm. Shaft load: . Axial40 NRadial110 N: . Axial: 40 N. Radial: 110 N. Dimensions: . Length55.7 mmDiameter58 mm: . Length: 55.7 mm. Diameter: 58 mm

Brand	Pepperl Fuchs
Lifecycle status	active
