F2D0-TI-Ex8.FF.*

Temperature Multi-Input. Temperature multi-input, stand-alone device with aluminum housing for field installation, For 8 temperature or analog sensors, Installation in Zone 1/Div. 1, intrinsically saf...

Temperature Multi-Input. Temperature multi-input, stand-alone device with aluminum housing for field installation, For 8 temperature or analog sensors, Installation in Zone 1/Div. 1, intrinsically safe, Sensors in Zone 0/Div. 1, Connection to fieldbus acc. to FISCO or Entity, For FOUNDATION Fieldbus H1, IECEx approval, Dust protection, International, Europe, USA, Canada. Design / Mounting: Outside installation. Installation in hazardous area: Zone 1 / Div. 1. Electronic component: Temperature Multi-Input Device RD0-TI-Ex8.FF* For technical data on installed electronic component see datasheet.. Fieldbus type: FOUNDATION Fieldbus. Number: 8. Electromagnetic compatibility: . Directive 2014/30/EUEN 61326-1:2013: . Directive 2014/30/EU: EN 61326-1:2013. Galvanic isolation: EN 60079-11. Electromagnetic compatibility: NE 21:2011. Degree of protection: IEC 60529. Fieldbus standard: IEC 61158-2. Shock resistance: EN 60068-2-27. Vibration resistance: EN 60068-2-6. Ambient temperature: see table 1. Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Relative humidity: ≤ 95 % non-condensing. Shock resistance: 15 g , 11 ms. Vibration resistance: 10 g , 10 ... 150 Hz. Corrosion resistance: acc. to ISA-S71.04-1985, severity level G3. Connection type: plug-in terminals , spring terminal and screw terminal. Core cross section: . Busup to 2.5 mm2Inputsup to 2.5 mm2: . Bus: up to 2.5 mm2. Inputs: up to 2.5 mm2. Cable diameter: see table 2. Cable gland: sensor inputs M16, fieldbus M20. Housing material: Aluminum. Degree of protection: IP67. Mass: 1800 g. Mounting: wall mounting. EU-type examination certificate: PTB 03 ATEX 2237. Marking II 2 (1) G Ex ia [ia Ga] IIC T4 Gb , [exsign] II (1) G [Ex ia Ga] IIC , [exsign] II (1) D [Ex ia Da] IIIC , [exsign] II 3 G Ex ic IIC T4 Gc: . Marking: II 2 (1) G Ex ia [ia Ga] IIC T4 Gb , [exsign] II (1) G [Ex ia Ga] IIC , [exsign] II (1) D [Ex ia Da] IIIC , [exsign] II 3 G Ex ic IIC T4 Gc. Bus: FISCO see EC-Type Examination Certificate. Inputs: see EC-Type Examination Certificate. Certificate: PTB 03 ATEX 2238 X. Marking II 3 G Ex nA IIC T4 Gc: . Marking: II 3 G Ex nA IIC T4 Gc. Galvanic isolation: . Bussee Statement of ConformityInputsee EC-Type Examination Certificate: . Bus: see Statement of Conformity. Input: see EC-Type Examination Certificate. Directive conformity: . Directive 2014/34/EUEN IEC 60079-0:2018+AC:2020 , EN 60079-11:2012 , EN 60079-15:2010: . Directive 2014/34/EU: EN IEC 60079-0:2018+AC:2020 , EN 60079-11:2012 , EN 60079-15:2010. FM approval: . FM certificateFM18US0054X , FM18CA0027XControl drawing16-473FM-12A: . FM certificate: FM18US0054X , FM18CA0027X. Control drawing: 16-473FM-12A. IECEx approval: . IECEx certificateIECEx PTB 05.0001 IECEx PTB 05.0002XIECEx markingEx ia [ia Ga] IIC T4 Gb [Ex ia Ga] IIC [Ex ia Da] IIIC Ex ic IIC T4 Gc Ex nA IIC T4 Gc: . IECEx certificate: IECEx PTB 05.0001 IECEx PTB 05.0002X. IECEx marking: Ex ia [ia Ga] IIC T4 Gb [Ex ia Ga] IIC [Ex ia Da] IIIC Ex ic IIC T4 Gc Ex nA IIC T4 Gc. Supplementary information: EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity, Attestation of Conformity and instructions have to be observed where applicable. For information see www.pepperl-fuchs.com.

Brand	Pepperl Fuchs
Lifecycle status	active
