GL-ES-IR/115/120

Photoelectric slot sensor. Photoelectric slot sensor, Infrared light source, Not sensitive to ambient light, High switching frequency, Robust and insensitive to ambient interference, Tolerant to suppl...

Photoelectric slot sensor. Photoelectric slot sensor, Infrared light source, Not sensitive to ambient light, High switching frequency, Robust and insensitive to ambient interference, Tolerant to supply voltage variations up 60 V DC. Sensing range: 0 ... 24 mm. Light source: LED. Light type: infrared , 950 nm. Tests: EN 60947-5-2. Marking: CE. Slot width: 24 mm. Slot depth: 24 mm. Ambient light limit: halogen light 100000 Lux ; according to EN 60947-5-2:2007. Operation indicator: LED red. Operating voltage: 10 ... 30 V DC. Ripple: 10 %. No-load supply current: < 30 mA. Time delay before availability: ≤ 10 ms. Switching type: light/dark on. Signal output: 2 PNP complementary , Reverse polarity protection , open collectors. Switching voltage: max. 30 V DC. Switching current: max. 100 mA. Voltage drop: ≤ 2 V. Switching frequency: 100 Hz. Response time: 5 ms. Product standard: EN 60947-5-2. Ambient temperature: -25 ... 55 °C (-13 ... 131 °F). Storage temperature: -30 ... 70 °C (-22 ... 158 °F). Degree of protection: IP67. Connection: 2 m fixed cable. Material: . HousingPPOOptical facePC: . Housing: PPO. Optical face: PC

Brand	Pepperl Fuchs
Lifecycle status	active
