HR-021**1

Hydrostatic Pressure Switch. Limit value detection for liquids as maximum detection, High switching capacity, Used in open or pressureless vessels. Equipment architecture: switching element: changeove...

Hydrostatic Pressure Switch. Limit value detection for liquids as maximum detection, High switching capacity, Used in open or pressureless vessels. Equipment architecture: switching element: changeoverswitching on point: 15 mbar ± 3 mbar, switching off point: 9 mbar ± 3 mbarmax. hydrostatic pressure: 500 mbar. Series: HR-021**1. Rated voltage: 253 V AC , 50/60 Hz. Current consumption: max. 1 A. Degree of protection: IEC 60529:2001. Process conditions: . Process temperature-20 ... 70 °C (-4 ... 158 °F): . Process temperature: -20 ... 70 °C (-4 ... 158 °F). Ambient temperature: -20 ... 70 °C (-4 ... 158 °F). Degree of protection: IP54. Connection: flat plug 6.3 x 0.8 mm (0.25 x 0.03 inch), DIN 46244. Material: housing: PApipe: stainless steel 1.4571/316Ti or PVC. Dimensions: housing: 100 x 75 x 80 mm (4 x 3 x 3.1 inch)pipe: length L 180 ... 5000 mm (0.6 ... 16.5 ft). Process connection: thread G1/2 to ISO 228. Supplementary information: Statement of Conformity, Declaration of Conformity, Attestation of Conformity and instructions have to be observed where applicable. For information see www.pepperl-fuchs.com.

Brand	Pepperl Fuchs
Lifecycle status	active
