ICRPB-4DB9M-PM

Breakout Box. 4 DB-9M connectors. UL File Number: E185802. MTBF: 119.1 a. Surge protection: 15 KV / 200 A for 1 ns. Interface type: Software selectable interfaces: RS-232 , RS-422 , RS-485. Physical:...

Breakout Box. 4 DB-9M connectors. UL File Number: E185802. MTBF: 119.1 a. Surge protection: 15 KV / 200 A for 1 ns. Interface type: Software selectable interfaces: RS-232 , RS-422 , RS-485. Physical: 4 x DB9. Supported baud rates: 300 to 460.8 Kbps. Electromagnetic compatibility: . Directive 2014/30/EUEN 61000-4-2:2009 EN 61000-4-3:2006+A1:2008+A2:2010 EN 61000-4-4:2012 EN 61000-4-5:2014+A1:2017 EN 61000-4-6:2014 EN 61000-4-11:2004+A1:2017: . Directive 2014/30/EU: EN 61000-4-2:2009 EN 61000-4-3:2006+A1:2008+A2:2010 EN 61000-4-4:2012 EN 61000-4-5:2014+A1:2017 EN 61000-4-6:2014 EN 61000-4-11:2004+A1:2017. RoHS: EN IEC 63000:2018. Electromagnetic compatibility: . Electrical safety: CSA C22.2 No. 60950 / UL60950. Emitted interference: EN 55032:2015 FCC CFR 47, part 15, subpart B: 2017 ICES-003 AS/NZ5 CISPR 32, FCC Part 15 Subpart B Class A. Noise immunity: EN 55035:2017-07. Ambient temperature: 0 ... 60 °C (32 ... 140 °F). Storage temperature: -20 ... 85 °C (-4 ... 185 °F). Relative humidity: max. 95 % non-condensing. Altitude: 0 ... 3048 m. Mass: 275 g. Dimensions: . Height22.9 mmWidth76.2 mmLength139.7 mm: . Height: 22.9 mm. Width: 76.2 mm. Length: 139.7 mm. Construction type: Metal housing. Mounting: panel mount

Brand	Pepperl Fuchs
Lifecycle status	active
