IPH-30GM-Ex

RFID read/write device hazardous area. LF RFID read/write device for IDENT<i>Control</i>, for hazardous areas. Operating frequency: 125 kHz. Transfer rate: 2 kBit/s. MTBF: 350 a (Operation at +40 °C)....

RFID read/write device hazardous area. LF RFID read/write device for IDENT<i>Control</i>, for hazardous areas. Operating frequency: 125 kHz. Transfer rate: 2 kBit/s. MTBF: 350 a (Operation at +40 °C). Power consumption: ≤ 1.2 W. Supply: from the IDENTControl. Radio equipment: . Directive 2014/53/EUEN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364: . Directive 2014/53/EU: EN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364. RoHS: . Directive 2011/65/EU (RoHS)IEC/EN 63000: . Directive 2011/65/EU (RoHS): IEC/EN 63000. Explosion protection: EN IEC 60079-0EN 60079-18/A1. Degree of protection: EN 60529. RFID: ISO/IEC 18000-2. ATEX approval: . Marking II 2G Ex mb IIC T4 Gb [exsign] II 2D Ex mb IIIC T130°C DbEquipment protection level GbIBExU 21ATEX1039 XEquipment protection level DbIBExU 21ATEX1039 X: . Marking: II 2G Ex mb IIC T4 Gb [exsign] II 2D Ex mb IIIC T130°C Db. Equipment protection level Gb: IBExU 21ATEX1039 X. Equipment protection level Db: IBExU 21ATEX1039 X. Ambient temperature: -20 ... 70 °C (-4 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Degree of protection: IP68. Connection: 15 m connecting cable included with delivery Connection e.g. with terminal boxes Series GL5. Material: . HousingStainless steel 1.4305 / AISI 303: . Housing: Stainless steel 1.4305 / AISI 303. Installation: flush. Distance between two headsMultiplex on: ≥ 155 mm Multiplex off: ≥ 350 mm: . Distance between two heads: Multiplex on: ≥ 155 mm Multiplex off: ≥ 350 mm. Mass: approx. 2000 g. Dimensions: . Length105 mm ± 1 mmDiameter38 mm: . Length: 105 mm ± 1 mm. Diameter: 38 mm. Use in the hazardous area: see instruction manuals

Brand	Pepperl Fuchs
Lifecycle status	active
