IPH-F61-V1

RFID read/write device. LF RFID read/write device for IDENT<i>Control</i>. Operating frequency: 125 kHz. Transfer rate: 2 kBit/s. Sensing range: . Read distance2 ... 45 mmWrite distance2 ... 35 mmWidt...

RFID read/write device. LF RFID read/write device for IDENT<i>Control</i>. Operating frequency: 125 kHz. Transfer rate: 2 kBit/s. Sensing range: . Read distance2 ... 45 mmWrite distance2 ... 35 mmWidthmax. 65 mm: . Read distance: 2 ... 45 mm. Write distance: 2 ... 35 mm. Width: max. 65 mm. UL File Number: E87056. MTBF: 350 a (Operation at +40 °C). Power consumption: ≤ 1.2 W. Supply: from the IDENTControl. Radio equipment: . Directive 2014/53/EUEN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364: . Directive 2014/53/EU: EN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364. RoHS: . Directive 2011/65/EU (RoHS)IEC/EN 63000: . Directive 2011/65/EU (RoHS): IEC/EN 63000. Degree of protection: EN 60529. RFID: ISO/IEC 18000-2. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Degree of protection: IP67. Connection: connector M12 x 1. Material: . HousingABSEncapsulation compoundWEVO 403FL/300: . Housing: ABS. Encapsulation compound: WEVO 403FL/300. Installation: . Distance between two headsMultiplex on: ≥ 50 mm Multiplex off: ≥ 290 mm: . Distance between two heads: Multiplex on: ≥ 50 mm Multiplex off: ≥ 290 mm. Mass: approx. 50 g. Dimensions: . Height12 mmWidth28 mmLength80 mm: . Height: 12 mm. Width: 28 mm. Length: 80 mm. Cable length: 20 cm

Brand	Pepperl Fuchs
Lifecycle status	active
