IQC21-30-EX smart-DOME 50pcs

RFID Transponder. Data carrier for hazardous area. Marking: II 2G Ex ia IIC T6 Gb [exsign] II 2D Ex ia IIIC T80°C Db. Operating frequency: 13.56 MHz. Transfer rate: 26 kBit/s. Chip Type: I-CODE SLI (N...

RFID Transponder. Data carrier for hazardous area. Marking: II 2G Ex ia IIC T6 Gb [exsign] II 2D Ex ia IIIC T80°C Db. Operating frequency: 13.56 MHz. Transfer rate: 26 kBit/s. Chip Type: I-CODE SLI (NXP). EEPROM: 896 Bit. UID: 64 Bit. Memory organization: 4 bytes/block. Read cycles: unlimited. Write cycles: > 100000. Data retention period: 10 years at 55 °C (131 °F). Explosion protection: . Directive 2014/34/EUEN IEC 60079-0 EN IEC 60079-11: . Directive 2014/34/EU: EN IEC 60079-0 EN IEC 60079-11. Radio equipment: . Directive 2014/53/EUEN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364: . Directive 2014/53/EU: EN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364. RoHS: . Directive 2011/65/EU (RoHS)IEC/EN 63000: . Directive 2011/65/EU (RoHS): IEC/EN 63000. Degree of protection: EN 60529. RFID: ISO/IEC 15693-1 ISO/IEC 15693-2 ISO/IEC 15693-3 ISO/IEC 18000-3. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 110 °C (-40 ... 230 °F). Degree of protection: IP67. Material: . HousingPolyurethane (PUR): . Housing: Polyurethane (PUR). Installation: . On metalyesIn airyes: . On metal: yes. In air: yes. Dimensions: . Height10 mmDiameter30 mm: . Height: 10 mm. Diameter: 30 mm. Construction type: Cylindrical. Note: Packaging unit, 50-piece

Brand	Pepperl Fuchs
Lifecycle status	active
