IUT-F191-IO-V1-FR1-04

RFID read/write device. UHF RFID read/write device with IO-Link, India. Operating frequency: 865 MHz … 867 MHz: IndiaTransmission licenses for other countries on request. Emitted power: 3 … 100 mW ERP...

RFID read/write device. UHF RFID read/write device with IO-Link, India. Operating frequency: 865 MHz … 867 MHz: IndiaTransmission licenses for other countries on request. Emitted power: 3 … 100 mW ERP adjustable. MTBF: 127 a (Operation at +40 °C). LED green/red: Solid green: Ready for operation, no IO-Link communicationFlashing green (1 Hz): IO-Link operation. LED yellow: Read/write operation successful. LED blue: Transmission mode. Operating voltage: 18 ... 30 V DC (IO-Link). Current consumption: ≤ 90 mA ( at 24 V DC ). Interface type: IO-Link. IO-Link revision: 1.1. Device profile: Identification and Diagnosis - I&D. Process data: Input 32 Byte Output 32 Byte. Vendor ID: 1 (0x0001). Device ID: 4194820 (0x400204). Data transfer rate: COM3 (230.4 kbits/s). Min. cycle time: 4 ms. SIO mode support: no. Compatible master port type: Class A Class B. Degree of protection: EN 60529. Communication interface: IEC 61131-9 / IO-Link V1.1.3. RFID: ISO/IEC 18000-63. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F) (Operation with nontransmission periods) -25 ... 60 °C (-13 ... 140 °F) (Continuous transmission mode). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Degree of protection: IP67. Connection: connector M12 x 1. Material: . HousingPA 6.6BaseAluminum: . Housing: PA 6.6. Base: Aluminum. Mass: 700 g. Dimensions: . Height47 mmWidth165 mmLength165 mm: . Height: 47 mm. Width: 165 mm. Length: 165 mm

Brand	Pepperl Fuchs
Lifecycle status	active
