KCD2-R

Sensor output interface terminal. Relay output with 1 pole, yellow LED indicates switching state, Free-wheeling diode, Compact terminal housing, Clips onto standard 35 mm rail to DIN EN 50 022, Degree...

Sensor output interface terminal. Relay output with 1 pole, yellow LED indicates switching state, Free-wheeling diode, Compact terminal housing, Clips onto standard 35 mm rail to DIN EN 50 022, Degree of protection IP20, Operating voltage: 24 V DC ± 15 %, Connectable sensor types: PNP or NPN 3-wire sensors, Relay: 1 changeover contact. MTTFd: 19699 a. LED yellow: switch output. Operating voltage: 24 V DC ± 15 %. Ripple: ≤ 10 %. Operating current: 16 mA. Connection: terminals 2+, 3-. Connectable sensor types: PNP or NPN 3-wire sensors. Switching frequency: ≤ 10 Hz. Relay: 1 changeover contact. Contact loading: 30 V DC/2 A resistive load. Delay: Pull-in: approx. 6 ms Drop-out: approx. 2 ms. Mechanical life: ≥108 switching cycles. Electromagnetic compatibility: . Directive 2014/30/EUEN 61326-1:2013: . Directive 2014/30/EU: EN 61326-1:2013. Degree of protection: EN 60529:2000. Noise immunity: EN 61326-1:2013. Ambient temperature: -25 ... 60 °C (-13 ... 140 °F). Storage temperature: -25 ... 85 °C (-13 ... 185 °F). Degree of protection: IP20. Connection: self-opening apparatus connection terminals, max. core cross-section 0.34 ... 2.5 mm2. Mass: 60 g. Dimensions: 20 mm x 60 mm x 40 mm

Brand	Pepperl Fuchs
Lifecycle status	active
