KIT-BT-V1-N0

Bluetooth®-Kit for VisuNet FLX Systems. Bluetooth®-Kit for VisuNet FLX Systems, Compatible with VisuNet FLX housing AG-3200-*, Consists of USB stick, cable and socket wrench for mounting, Bluetooth® s...

Bluetooth®-Kit for VisuNet FLX Systems. Bluetooth®-Kit for VisuNet FLX Systems, Compatible with VisuNet FLX housing AG-3200-*, Consists of USB stick, cable and socket wrench for mounting, Bluetooth® standards: v4.0 (Backwards compatible with Bluetooth® v2.0, v2.1 and v3.0), Certification: CE, FCC, Prepared for mounting into VisuNet FLX blind plug dome. Power supply: 5 V DC (Power supply via USB) Crystal Oscillator: 20 MHz. Data rate: up to 3 MBit/s. Operation frequency: 2.4 GHz to 2.485 GHz. Bluetooth: Tx Output Power: 0 dBm (Bluetooth® v2.0, v2.1) and 4.7 dBm (Bluetooth® Smart)Rx Sensitivity: -82 dBm (Bluetooth® v2.0, v2.1) v4.0 low energy and v2.0, v2.1 wireless technologies. USB: USB 2.0. Operating system: RM Shell 5 and newer Based on Microsoft® Windows 10 IoT Enterprise LTSC 2019. Operating temperature: -30 ... 85 °C (-22 ... 185 °F). Certificate: Certified for use in the VisuNet FLX System in ATEX and IECEx Zone 2/22 installations. Approved for: CE, FCC, RoHS, REACH and WEEE. Supplementary information: Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. An additonal driver is required. Please refer to the software tool tab to install your specific driver.

Brand	Pepperl Fuchs
Lifecycle status	active
