MH-EXG-18

Mounting aid. Quick mounting bracket with dead stop, Clamp for threaded pipe, Suitable for all M18 sensors, including reduction factor 1, Simple and quick exchange without readjustment, 2 panel nuts i...

Mounting aid. Quick mounting bracket with dead stop, Clamp for threaded pipe, Suitable for all M18 sensors, including reduction factor 1, Simple and quick exchange without readjustment, 2 panel nuts included, Free of paint wetting interfering substances. Ambient temperature: -40 ... 90 °C (-40 ... 194 °F). Length: 35 mm thread length of sensor min. 35 mm. Diameter: sensor min. 17.8 mm sensor max. 18 mm. Connection: M24 x 1.5 external thread. Material: brass, nickel-plated free of paint wetting interfering substances. Screwed connection: SW = 30 mm. Dimensions: . Length35 mmDiameter33 mm: . Length: 35 mm. Diameter: 33 mm. Tightening torque: 25 Nm nuts 5 6 Nm nut 1. Note: Attention: Sensor shape dependent, it will be fixed up to 0.7 mm in back-flush position.

Brand	Pepperl Fuchs
Lifecycle status	active
