MPR1HD

Thru-beam sensor receiver. Photoelectric Sensors; MP Series Modular, Receiver, Harsh duty, Withstands 1200 psi washdown, Sensing range 60 m. Sensing range: 60 meters. Light source: Infrared. Light typ...

Thru-beam sensor receiver. Photoelectric Sensors; MP Series Modular, Receiver, Harsh duty, Withstands 1200 psi washdown, Sensing range 60 m. Sensing range: 60 meters. Light source: Infrared. Light type: infrared. Marking: CE. Function indicator: 2 LEDs. Control elements: light on / dark on. Response time: ≤ 10 ms. Output type: dependent on base selected. Standards: EN 60947-5-2. Approvals: CE, cULus. Ambient temperature: -30 ... 70 °C (-22 ... 158 °F). Storage temperature: -55 ... 85 °C (-67 ... 185 °F). Relative humidity: 95% RH (non-condensing). Shock resistance: 50G. Vibration resistance: 10G, 10 ... 500 Hz. Degree of protection: IP69K. Material: . HousingPolycarbonateOptical faceGlass LensSheathingGlass-filled acetal, Type 20: . Housing: Polycarbonate. Optical face: Glass Lens. Sheathing: Glass-filled acetal, Type 20. Dimensions: . Height43.2 mmWidth39.6 mmDepth52.3 mm: . Height: 43.2 mm. Width: 39.6 mm. Depth: 52.3 mm

Brand	Pepperl Fuchs
Lifecycle status	active
