NBB10-F17-E2

Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: flush, Output polarity: DC, Output type: 3-wire, Construction type: Rectangular, Series: Rectangular type, Ope...

Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: flush, Output polarity: DC, Output type: 3-wire, Construction type: Rectangular, Series: Rectangular type, Operating voltage: 10 ... 30 V DC, Type of voltage: DC, Connection type: cable, Housing material: PMMA, Degree of protection: IP67, Material: PUR. Switching function: Normally open (NO). Output type: PNP. Rated operating distance: 10 mm. Installation: flush. Output polarity: DC. Assured operating distance: 0 ... 8.1 mm. Actual operating distance: 9 ... 11 mm typ. 10 mm. Reduction factor rAl: 0.36. Reduction factor rCu: 0.31. Reduction factor r304: 0.67. Output type: 3-wire. Operating voltage: 10 ... 30 V DC. Switching frequency: 0 ... 1000 Hz. Hysteresis: 1 ... 10 % typ. 6 %. Reverse polarity protection: reverse polarity protected. Short-circuit protection: pulsing. Voltage drop: ≤ 2.8 V. Operating current: 0 ... 100 mA. No-load supply current: 10 mA. Time delay before availability: ≤ 1 ms. Switching state indicator: LED, yellow. MTTFd: 1881 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 30 V DC Output Switching Current: 100 mA. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: cable. Housing material: PMMA. Sensing face: PMMA. Degree of protection: IP67. Cable: . Wire end ferrulesyesCable diameter3 mm - 0.2 mmBending radius> 12 x cable diameterMaterialPURColorblackNumber of cores3Core cross section0.14 mm2LengthL2 m: . Wire end ferrules: yes. Cable diameter: 3 mm - 0.2 mm. Bending radius: > 12 x cable diameter. Material: PUR. Color: black. Number of cores: 3. Core cross section: 0.14 mm2. Length: 2 m. Dimensions: . Height30 mmWidth50 mmLength7 mm: . Height: 30 mm. Width: 50 mm. Length: 7 mm. Tightening torque: 0.5 Nm ... 0.6 Nm

Brand	Pepperl Fuchs
Lifecycle status	active
