NBB3-V3-Z4-V5

Inductive sensor. Switching function: Normally open (NO), Output type: Two-wire, Installation: flush, Output polarity: DC, Output type: 2-wire, Construction type: Rectangular, Series: Rectangular type...

Inductive sensor. Switching function: Normally open (NO), Output type: Two-wire, Installation: flush, Output polarity: DC, Output type: 2-wire, Construction type: Rectangular, Series: Rectangular type, Operating voltage: 5 ... 60 V DC, Type of voltage: DC, Connection type: 4.8 mm Faston, Housing material: PBT, Degree of protection: IP67. Switching function: Normally open (NO). Output type: Two-wire. Rated operating distance: 3 mm. Installation: flush. Output polarity: DC. Assured operating distance: 0 ... 2.4 mm. Actual operating distance: 2.7 ... 3.3 mm typ.. Reduction factor rAl: 0.45. Reduction factor rCu: 0.35. Reduction factor r304: 0.8. Reduction factor rBrass: 0.5. Output type: 2-wire. Operating voltage: 5 ... 60 V DC. Switching frequency: 0 ... 2000 Hz. Hysteresis: typ. 0.2 mm. Reverse polarity protection: reverse polarity protected. Short-circuit protection: no. Inductive overvoltage protection: yes. Voltage drop: ≤ 4 V. Voltage drop at IL: . Voltage drop IL = 10 mA, switching element onUd3.4 ... 3.9 V typ. 3.6 V: Ud. Voltage drop IL = 10 mA, switching element on: 3.4 ... 3.9 V typ. 3.6 V. Operating current: 4 ... 100 mA. Lowest operating current: 4 mA. Off-state current: 0.4 ... 0.55 mA typ. 0.46 mA. Time delay before availability: ≤ 1 ms. Switching state indicator: LED, yellow. Tightening torque, fastening screws: 0.4 Nm. MTTFd: 1552 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. EMC in accordance with: EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 60 V DC Output Switching Current: 100 mA. CCC approval: Certified by China Compulsory Certification (CCC). Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Connection type: 4.8 mm Faston. Housing material: PBT. Sensing face: PBT. Degree of protection: IP67. Dimensions: . Height10.2 mmWidth27.8 mmLength16 mm: . Height: 10.2 mm. Width: 27.8 mm. Length: 16 mm

Brand	Pepperl Fuchs
Lifecycle status	active
