NBB30-L2K-E2-V1
Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: flush, Output polarity: DC, Output type: 3-wire, Construction type: <i>VariKont L</i> <sup>®</sup>, Series: <i...
Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: flush, Output polarity: DC, Output type: 3-wire, Construction type: <i>VariKont L</i> <sup>®</sup>, Series: <i>VariKont L</i> <sup>®</sup>, Operating voltage: 10 ... 30 V DC, Type of voltage: DC, Connection type: Connector plug, Housing material: PA, Degree of protection: IP68 / IP69, Threading: M12 x 1. Switching function: Normally open (NO). Output type: PNP. Rated operating distance: 30 mm. Installation: flush. Output polarity: DC. Assured operating distance: 0 ... 24.3 mm. Actual operating distance: 27 ... 33 mm typ.. Reduction factor rAl: 0.4. Reduction factor rCu: 0.37. Reduction factor r304: 0.76. Reduction factor rBrass: 0.46. Output type: 3-wire. Operating voltage: 10 ... 30 V DC. Switching frequency: 0 ... 60 Hz. Hysteresis: typ. 2 %. Reverse polarity protection: reverse polarity protected. Short-circuit protection: pulsing. Voltage drop: ≤ 2 V. Operating current: 0 ... 200 mA. Off-state current: 0 ... 0.5 mA. No-load supply current: ≤ 20 mA. Time delay before availability: 80 ms. Operating voltage indicator: LED, green. Switching state indicator: LED, yellow. MTTFd: 899 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 30 V DC Output Switching Current: 200 mA. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: Connector plug. Housing material: PA. Sensing face: PA. Degree of protection: IP68 / IP69. Connector: . ThreadingM12 x 1Number of pins4: . Threading: M12 x 1. Number of pins: 4. Mass: 130 g. Dimensions: . Height40 mmWidth40 mmLength67 mm: . Height: 40 mm. Width: 40 mm. Length: 67 mm
| Brand | Pepperl Fuchs |
| Lifecycle status | active |
