Pepperl Fuchs

NBB6-18GK10-E0-Y89851

Inductive sensor. Switching function: Normally open (NO), Output type: NPN, Installation: flush, Output polarity: DC, Output type: 3-wire, Thread mold: M18, Construction type: Cylindrical, thread, Series: Cylindrical type, Type of voltage: DC, Connection type: fixed cable with plug, Housing material: PBT, Degree of protection: IP67, Connector: Molex, Material: PVC. Switching function: Normally open (NO). Output type: NPN. Rated operating distance: 6 mm. Installation: flush. Output polarity: DC. Assured operating distance: 0 ... 4.86 mm. Reduction factor rAl: 0.2. Reduction factor rCu: 0.15. Reduction factor r304: 0.62. Output type: 3-wire. Operating voltage: 10 ... 30 V. Switching frequency: 0 ... 500 Hz. Reverse polarity protection: reverse polarity protected. Short-circuit protection: no. Voltage drop: ≤ 2 V. Operating current: 0 ... 100 mA. Off-state current: 0 ... 0.5 mA typ. 0.1 µA at 25 °C. No-load supply current: ≤ 20 mA. MTTFd: 5120 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed Load Type: Resistive Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 30 V DC Output Switching Current: 100 mA. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Connection type: fixed cable with plug. Housing material: PBT. Sensing face: PBT. Degree of protection: IP67. Connector: Molex. Number of pins3: . Number of pins: 3. Cable: . Cable diameter4.9 mm - 0.3 mmBending radius> 10 x cable diameterMaterialPVCColorblackNumber of cores3Core cross section0.34 mm2LengthL750 mm: . Cable diameter: 4.9 mm - 0.3 mm. Bending radius: > 10 x cable diameter. Material: PVC. Color: black. Number of cores: 3. Core cross section: 0.34 mm2. Length: 750 mm. Dimensions: . Length10 mmDiameter18 mm: . Length: 10 mm. Diameter: 18 mm

Brand	Pepperl Fuchs
Lifecycle status	active

Not currently in stock

Price on request
