NCB4-12GM60-B3-V1

Inductive sensor. Switching function: Normally open/closed (NO/NC) programmable, Output type: AS-Interface, Installation: flush, Output type: 2-wire, Thread mold: M12, Construction type: Cylindrical,...

Inductive sensor. Switching function: Normally open/closed (NO/NC) programmable, Output type: AS-Interface, Installation: flush, Output type: 2-wire, Thread mold: M12, Construction type: Cylindrical, thread, Series: Cylindrical type, Operating voltage: 26.5 ... 31.9 V via AS-i bus system, Type of voltage: DC, Connection type: Connector plug, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP67, Threading: M12 x 1. Switching function: Normally open/closed (NO/NC) programmable. Output type: AS-Interface. Rated operating distance: 4 mm. Installation: flush. Assured operating distance: 0 ... 3.24 mm. Actual operating distance: 3.6 ... 4.4 mm typ. 4 mm. Reduction factor rAl: 0.23. Reduction factor rCu: 0.21. Reduction factor r304: 0.7. Node type: Standard node. AS-Interface specification: V2.1. Required gateway specification: ≥ V2.1. Output type: 2-wire. Operating voltage: 26.5 ... 31.9 V via AS-i bus system. Switching frequency: 0 ... 500 Hz. Hysteresis: 1 ... 15 % typ. 5 %. Reverse polarity protection: reverse polarity protected. Voltage drop at IL: . Voltage drop IL = 20 mA, switching element onUd3.4 ... 5 V typ. 4.3 V: Ud. Voltage drop IL = 20 mA, switching element on: 3.4 ... 5 V typ. 4.3 V. No-load supply current: ≤ 25 mA. Time delay before availability: ≤ 1000 ms. Switching state indicator: dual-LED, yellow. Error indicator: dual-LED, red. MTTFd: 2140 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 31.9 V DC. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: Connector plug. Housing material: Stainless steel 1.4305 / AISI 303. Sensing face: PBT. Degree of protection: IP67. Connector: . ThreadingM12 x 1Number of pins4: . Threading: M12 x 1. Number of pins: 4. Dimensions: . Length60 mmDiameter12 mm: . Length: 60 mm. Diameter: 12 mm

Brand	Pepperl Fuchs
Lifecycle status	active
