NDP5-30GM-5M

WIS transmitter primary. Installation: non-flush. Transfer distance: 0 ... 5 mm. Output type: 2-wire. MTTFd: 31930 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. CCC approval: CCC approval...

WIS transmitter primary. Installation: non-flush. Transfer distance: 0 ... 5 mm. Output type: 2-wire. MTTFd: 31930 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: 0 ... 50 °C (32 ... 122 °F). Storage temperature: -25 ... 85 °C (-13 ... 185 °F). Connection type: cable. Housing material: brass, nickel-plated. Sensing face: PBT. Degree of protection: IP67. Cable: . Wire end ferrulesyesCable diameter6 mm ± 0.2 mmBending radius> 10 x cable diameterMaterialPVCColorgreyNumber of cores2Core cross section0.75 mm2LengthL5 m: . Wire end ferrules: yes. Cable diameter: 6 mm ± 0.2 mm. Bending radius: > 10 x cable diameter. Material: PVC. Color: grey. Number of cores: 2. Core cross section: 0.75 mm2. Length: 5 m. Installation: screw mounting. Free zoneA≥ 3 mmSpacing to metal wallsB≥ ∅ 50 mmSecurity zoneW x H≥ 60 mm x 15 mm: A. Free zone: ≥ 3 mm. Spacing to metal walls: ≥ ∅ 50 mm. Security zone: ≥ 60 mm x 15 mm. Dimensions: . Length43 mmDiameter30 mm: . Length: 43 mm. Diameter: 30 mm. Note: Maximum cable length between WIS module and WIS transmitter must not exceed 5 m.

Brand	Pepperl Fuchs
Lifecycle status	active
