NEB20-30GS50-E2-V1

Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: quasi flush, Output polarity: DC, Output type: 3-wire, Thread mold: M30, Construction type: Cylindrical, threa...

Inductive sensor. Switching function: Normally open (NO), Output type: PNP, Installation: quasi flush, Output polarity: DC, Output type: 3-wire, Thread mold: M30, Construction type: Cylindrical, thread, Series: Cylindrical type, Type of voltage: DC, Connection type: Connector plug, Housing material: Stainless steel 1.4305 / AISI 303, Degree of protection: IP68 / IP69K, Threading: M12 x 1. Switching function: Normally open (NO). Output type: PNP. Rated operating distance: 20 mm. Installation: quasi flush. Output polarity: DC. Assured operating distance: 0 ... 16.2 mm. Reduction factor rAl: 0.35. Reduction factor rCu: 0.25. Reduction factor r304: 0.72. Output type: 3-wire. Installation conditions: . A6 mmB37 mmC66 mmF90 mm: . A: 6 mm. B: 37 mm. C: 66 mm. F: 90 mm. Operating voltage: 10 ... 30 V. Switching frequency: 0 ... 120 Hz. Hysteresis: 2 ... 16 % typ. 8 %. Reverse polarity protection: reverse polarity protected. Short-circuit protection: pulsing. Voltage drop: ≤ 2 V. Operating current: 0 ... 200 mA. Off-state current: ≤ 0.1 mA. No-load supply current: ≤ 14 mA. Time delay before availability: max. 18 ms. Switching state indicator: Multihole-LED, yellow. MTTFd: 1493 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . StandardsEN IEC 60947-5-2: . Standards: EN IEC 60947-5-2. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 30 V DC Output Switching Current: 200 mA. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: Connector plug. Housing material: Stainless steel 1.4305 / AISI 303. Sensing face: PBT. Degree of protection: IP68 / IP69K. Connector: . ThreadingM12 x 1Number of pins3: . Threading: M12 x 1. Number of pins: 3. Mass: 145 g. Dimensions: . Length66 mmDiameter30 mm: . Length: 66 mm. Diameter: 30 mm. Scope of delivery: 2 self locking nuts in scope of delivery

Brand	Pepperl Fuchs
Lifecycle status	active
