OMT45-R103-2EP-IO

Distance sensor. Distance sensor, Miniature design with versatile mounting options, Space-saving distance sensors in small standardized design, Multi Pixel Technology (MPT) - exact and precise signal...

Distance sensor. Distance sensor, Miniature design with versatile mounting options, Space-saving distance sensors in small standardized design, Multi Pixel Technology (MPT) - exact and precise signal evaluation, IO-Link interface for service and process data. Measuring range: 15 ... 45 mm. Reference target: standard white, 100 mm x 100 mm. Light source: LED. Light type: modulated visible red light. LED risk group labelling: exempt group. Angle deviation: max. +/- 1.5 °. Diameter of the light spot: approx. 4 mm at a distance of 45 mm. Opening angle: approx. 4 °. Ambient light limit: EN 60947-5-2 : 30000 Lux. Resolution: 0.01 mm. MTTFd: 600 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Operation indicator: LED green:constantly on - power onflashing (4Hz) - short circuitflashing with short break (1 Hz) - IO-Link mode. Function indicator: LED yellow:constantly on - switch output activeconstantly off - switch output inactive. Control elements: Teach-In key. Control elements: 5-step rotary switch for operating modes selection. Operating voltage: 10 ... 30 V DC. Ripple: max. 10 %. No-load supply current: < 25 mA at 24 V supply voltage. Protection class: III. Interface type: IO-Link ( via C/Q = BK ). IO-Link revision: 1.1. Device profile: Smart Sensor. Device ID: 0x110907 (1116423). Transfer rate: COM2 (38.4 kBit/s). Min. cycle time: 3 ms. Process data width: Process data input 3 ByteProcess data output 2 Bit. SIO mode support: yes. Compatible master port type: A. Switching type: The default setting is: C/Q - BK: NPN normally open, PNP normally closed, IO-Link Q2 - WH: NPN normally open, PNP normally closed. Signal output: 2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected, overvoltage protected. Switching voltage: max. 30 V DC. Switching current: max. 100 mA , resistive load. Usage category: DC-12 and DC-13. Voltage drop: ≤ 1.5 V DC. Response time: 2 ms. Communication interface: IEC 61131-9. Product standard: EN 60947-5-2. Temperature drift: 20 µm/K. Warm up time: 5 min. Repeat accuracy: ≤ 0.2 mm. Linearity error: ± 0.3 mm. UL approval: E87056 , cULus Listed , class 2 power supply , type rating 1. Ambient temperature: 10 ... 60 °C (50 ... 140 °F) , cable, fixed installation 10 ... 60 °C (50 ... 140 °F) , movable cable not appropriate for conveyor chains. Storage temperature: -40 ... 70 °C (-40 ... 158 °F). Degree of protection: IP67 / IP69 / IP69K. Connection: 2 m fixed cable. Material: . HousingPC (Polycarbonate)Optical facePMMA: . Housing: PC (Polycarbonate). Optical face: PMMA. Mass: approx. 38 g. Dimensions: . Height36.5 mmWidth15 mmDepth26.7 mm: . Height: 36.5 mm. Width: 15 mm. Depth: 26.7 mm. Cable length: 2 m

Brand	Pepperl Fuchs
Lifecycle status	active
