PL3-F25-N4-S

Inductive sensor. Extended temperature range, Valve position detection, Solenoid valve output, Switching function: 2 x normally closed (NC), Output type: NAMUR, Installation: flush mountable, Output t...

Inductive sensor. Extended temperature range, Valve position detection, Solenoid valve output, Switching function: 2 x normally closed (NC), Output type: NAMUR, Installation: flush mountable, Output type: 2-wire, Construction type: Printed circuit board, Series: Pcb version, Suitable for 2:1 technology, Type of voltage: DC, Equipment protection level Ga: IECEx TUN 17.0021X, Equipment protection level Gb: IECEx TUN 17.0021X, Equipment protection level Mb: IECEx TUN 17.0021X, Equipment protection level Ga: TÜV 99 ATEX 1479 X. Switching function: 2 x normally closed (NC). Output type: NAMUR. Rated operating distance: 3 mm. Installation: flush mountable. Assured operating distance: 0 ... 2.43 mm. Actual operating distance: 2.6 ... 2.6 mm typ.. Reduction factor rAl: 0.52. Reduction factor rCu: 0.43. Reduction factor r304: 0.86. Reduction factor rSt37: 1. Reduction factor rBrass: 0.54. Output type: 2-wire. Nominal voltage: 8.2 V (Ri approx. 1 kΩ). Operating voltage: 5 ... 25 V. Switching frequency: 0 ... 100 Hz. Hysteresis: typ. 5 %. Reverse polarity protection: reverse polarity protected. Short-circuit protection: yes. Suitable for 2:1 technology: yes , Reverse polarity protection diode not required. Current consumption: . Measuring plate not detected≥ 3 mA at nominal voltageMeasuring plate detected≤ 1 mA at nominal voltage: . Measuring plate not detected: ≥ 3 mA at nominal voltage. Measuring plate detected: ≤ 1 mA at nominal voltage. Time delay before availability: ≤ 1 ms. Switching state indicator: LED, yellow. Valve status indicator: LED, yellowcan be switched off by of DB1. MTTFd: 834 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. Standard conformity: . NAMUREN 60947-5-6:2000 IEC 60947-5-6:1999Electromagnetic compatibilityNE 21:2007StandardsEN IEC 60947-5-2: . NAMUR: EN 60947-5-6:2000 IEC 60947-5-6:1999. Electromagnetic compatibility: NE 21:2007. Standards: EN IEC 60947-5-2. IECEx approval: . Equipment protection level GaIECEx TUN 17.0021XEquipment protection level GbIECEx TUN 17.0021XEquipment protection level MbIECEx TUN 17.0021X: . Equipment protection level Ga: IECEx TUN 17.0021X. Equipment protection level Gb: IECEx TUN 17.0021X. Equipment protection level Mb: IECEx TUN 17.0021X. ATEX approval: . Equipment protection level GaTÜV 99 ATEX 1479 XEquipment protection level GbTÜV 99 ATEX 1479 XEquipment protection level Gc (ic)PF13CERT2895 X: . Equipment protection level Ga: TÜV 99 ATEX 1479 X. Equipment protection level Gb: TÜV 99 ATEX 1479 X. Equipment protection level Gc (ic): PF13CERT2895 X. CCC approval: . Hazardous Location2020322315002262: . Hazardous Location: 2020322315002262. NEPSI approval: . NEPSI certificateGYJ19.1410X: . NEPSI certificate: GYJ19.1410X. Ambient temperature: -25 ... 100 °C (-13 ... 212 °F). Storage temperature: -40 ... 100 °C (-40 ... 212 °F). Connection (system side): screw terminals. Core cross section (system side): up to 2.5 mm2. Connection (valve side): screw terminals. Core cross section (valve side): up to 2.5 mm2. Housing material: PBT. Sensing face: PBT. Mass: 91 g. Tightening torque, fastening screws: ≤ 0.3 Nm. Dimensions: . Height99 mmWidth67 mmLength34 mm: . Height: 99 mm. Width: 67 mm. Length: 34 mm. Note: Installation in housing. Use in the hazardous area: see instruction manuals

Brand	Pepperl Fuchs
Lifecycle status	active
