PMI40-F90-U-V15

Inductive positioning system. Measuring range 0 ... 40 mm, Analog output 0 ... 10 V DC, Switching element function: analog voltage output, Output polarity: DC, Operating voltage: 12 ... 30 V DC, Type...

Inductive positioning system. Measuring range 0 ... 40 mm, Analog output 0 ... 10 V DC, Switching element function: analog voltage output, Output polarity: DC, Operating voltage: 12 ... 30 V DC, Type of voltage: DC, Output type: voltage output 0 ... 10 V DC, UL approval: cULus Listed <BR>Load Type: General Purpose <BR>Circuitry: Class 2 Power Source <BR>Enclosure Type Rating: Type 1 <BR>Supply/Switching Voltage: 30 V DC, Connection type: 5-pin, M12 x 1 connector, Degree of protection: IP67 / IP69K. Switching element function: analog voltage output. Object distance: 0.5 ... 3 mm , recommended: 1.5 mm. Measuring range: 0 ... 40 mm. Linearity range: 1 ... 39 mm. Operating voltage: 12 ... 30 V DC. Reverse polarity protection: reverse polarity protected. Linearity error: within measuring range: ± 0.8 mm within linearity range: ± 0.4 mm. Repeat accuracy: ± 0.1 mm. Resolution: 50 µm. Temperature drift: ± 0.5 mm (-25 °C ... 70 °C). No-load supply current: ≤ 40 mA. Operating voltage indicator: LED green. MTTFd: 365 a. Mission Time (TM): 20 a. Diagnostic Coverage (DC): 0 %. LED S3: Damping element in the configured analog measuring range. LED STATUS: LED, green/red. Output type: voltage output 0 ... 10 V DC. Load resistor: voltage output ≥ 1000 Ω. Short-circuit protection: voltage output: current limit. Standard conformity: . StandardsEN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 EN 60947-5-7:2003 IEC 60947-5-7:2003: . Standards: EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 EN 60947-5-7:2003 IEC 60947-5-7:2003. UL approval: cULus Listed Load Type: General Purpose Circuitry: Class 2 Power Source Enclosure Type Rating: Type 1 Supply/Switching Voltage: 30 V DC. Ambient temperature: -25 ... 85 °C (-13 ... 185 °F). Connection type: 5-pin, M12 x 1 connector. Degree of protection: IP67 / IP69K. Material: . HousingPBT, stainless steel 1.4571 , brass, nickel-platedTargetmild steel, e. g. 1.0037, SR235JR (formerly St37-2): . Housing: PBT, stainless steel 1.4571 , brass, nickel-plated. Target: mild steel, e. g. 1.0037, SR235JR (formerly St37-2). Mass: 56 g. Dimensions: . Height40 mmWidth23 mmLength60.3 mm: . Height: 40 mm. Width: 23 mm. Length: 60.3 mm

Brand	Pepperl Fuchs
Lifecycle status	active
