RaCon-D SI
Radar motion sensor. Premium radar motion sensor, Detection of people and objects for automatic doors, Fine tuning of functions and setting adjustment range, Remote control or push button for function...
Radar motion sensor. Premium radar motion sensor, Detection of people and objects for automatic doors, Fine tuning of functions and setting adjustment range, Remote control or push button for functionality setting, Wall and ceiling mountable, Function: Open, Sensor principle: Radar sensor, Operating voltage: 12 ... 24 V DC , - 10 % / +30 % <BR>12 ... 24 V AC , 50 ... 60 Hz , -10 % / +15 %, Signal output: solid-state relay, Connection: Connecting cable 2.5 m included with delivery. Sensing range: 2000 x 4500 mm (DxW) at 2200 mm mounting height and 60° inclination angle 4000 x 2000 mm (DxW) at 2200 mm mounting height and 60° inclination angle. Function principle: Microwave module. Detection speed: min. 0.05 m/s. Setting angle: . Rotation angle-30 ... 30 ° in 5 ° incrementsInclination angle0 ... 90 ° in 5 ° increments: . Rotation angle: -30 ... 30 ° in 5 ° increments. Inclination angle: 0 ... 90 ° in 5 ° increments. Operating frequency: 24.15 ... 24.25 GHz K-Band. Operating mode: Radar motion sensor. Transmitter radiated power (EIRP): < 13 dBm. MTTFd: 520 a. Mission Time (TM): 15 a. Diagnostic Coverage (DC): 0 %. Function indicator: detection : LED green push button indication : LED yellow / green. Control elements: Push button for selection of operating modes : sensitivity , direction detection , cross-traffic suppression , slow-motion mode , relay switching type, hold time, immunity, swing door mounting. Control elements: Operation mode selection alternativly via remote control (Accessories ordered separately). Operating voltage: 12 ... 24 V DC , - 10 % / +30 % 12 ... 24 V AC , 50 ... 60 Hz , -10 % / +15 %. No-load supply current: ≤ 35 mA at 24 V DC. Power consumption: ≤ 0.85 W ≤ 1 VA. Switching type: Normally open/closed (NO/NC). Signal output: solid-state relay. Switching voltage: max. 28 V AC / 36 V DC. Switching current: max. 0.1 A AC / 0.1 A DC. Hold time: min. 1.5 s max 20 s. CE conformity: 2014/53/EU This device can be used in all countries within the European Union. In other countries, all applicable national regulations must be observed.. Operating temperature: -25 ... 55 °C (-13 ... 131 °F). Storage temperature: -30 ... 70 °C (-22 ... 158 °F). Relative humidity: max. 90 % non-condensing. Mounting height: max. 4 m. Degree of protection: IP54. Connection: Connecting cable 2.5 m included with delivery. Material: . HousingPC (Polycarbonate): . Housing: PC (Polycarbonate). Mass: approx. 120 g. Dimensions: 120 mm x 55 mm x 54 mm. Height55 mmWidth120 mmDepth54 mm: . Height: 55 mm. Width: 120 mm. Depth: 54 mm
| Brand | Pepperl Fuchs |
| Lifecycle status | active |
