UB2000-F54-E5-V15

Ultrasonic sensor. Single head system, Switching output, 5 different output functions can be set, Program input, Series: UB-F54, Operating voltage: 10 ... 30 V DC , ripple 10 %_SS, Output ty...

Ultrasonic sensor. Single head system, Switching output, 5 different output functions can be set, Program input, Series: UB-F54, Operating voltage: 10 ... 30 V DC , ripple 10 %_SS, Output type: 1 switch output E5, PNP, NO/NC, UL approval: cULus Listed, Class 2 Power Source, CCC approval: CCC approval / marking not required for products rated ≤36 V, Connection type: Connector plug M12 x 1 , 5-pin, Housing: ABS. Sensing range: 80 ... 2000 mm. Adjustment range: 100 ... 2000 mm. Dead band: 0 ... 80 mm. Standard target plate: 100 mm x 100 mm. Transducer frequency: approx. 175 kHz. Response delay: ≤ 150 ms. LED green: solid green: monitoring systemgreen flashing: program function. LED yellow: indication of the switching stateflashing: program function object detected. LED red: flashing:normal mode: errorProgram function: no object detectedpermanently:Program mode, object uncertain. Operating voltage: 10 ... 30 V DC , ripple 10 %SS. No-load supply current: ≤ 55 mA. Synchronization: 1 synchronous input0-level: -UB...+1 V1-level: +4 V...+UB input impedance: > 12 KOhmsynchronization pulse: 0,1 ... 28 ms. Synchronization frequency: . Common mode operationmax. 33 HzMultiplex operation≤ 33 / n Hz, n = number of sensors: . Common mode operation: max. 33 Hz. Multiplex operation: ≤ 33 / n Hz, n = number of sensors. Input type: 1 program input,switching point A1: -UB ... +1 V, switching point A2: +4 V ... +UB input impedance: > 4.7 kΩ, program pulse: ≥ 1 s. Output type: 1 switch output E5, PNP, NO/NC. Rated operating current: 200 mA , short-circuit/overload protected. Voltage drop: ≤ 3 V. Repeat accuracy: ≤ 1 % of full-scale value. Switching frequency: max. 3 Hz. Range hysteresis: ≤ 1 % of the set operating distance. Temperature influence: ± 1.5 % of full-scale value. Standard conformity: . StandardsEN IEC 60947-5-2:2020 IEC 60947-5-2:2019: . Standards: EN IEC 60947-5-2:2020 IEC 60947-5-2:2019. UL approval: cULus Listed, Class 2 Power Source. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: -25 ... 70 °C (-13 ... 158 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: Connector plug M12 x 1 , 5-pin. Degree of protection: IP65. Material: . HousingABSTransducerepoxy resin/hollow glass sphere mixture; polyurethane foam: . Housing: ABS. Transducer: epoxy resin/hollow glass sphere mixture; polyurethane foam. Mass: 100 g. Dimensions: . Height31 mmWidth105 mmLength25 mm: . Height: 31 mm. Width: 105 mm. Length: 25 mm

Brand	Pepperl Fuchs
Lifecycle status	active
