UBE15M-F54-H2-V1

Ultrasonic sensor, receiver. Multi-head system, Large sensing range, Large possible lateral distance between emitter and receiver, Separate evaluation, Sensing range: 0 ... 15000 mm , emitter - receiv...

Ultrasonic sensor, receiver. Multi-head system, Large sensing range, Large possible lateral distance between emitter and receiver, Separate evaluation, Sensing range: 0 ... 15000 mm , emitter - receiver synchronised, Series: UB-F54, Operating voltage: 10 ... 30 V DC , ripple 10 %_SS. Sensing range: 0 ... 15000 mm , emitter - receiver synchronised. Transducer frequency: approx. 40 kHz. Opening angle: ± 45 ° at -6 dB. Temperature drift of echo propagation delay: 0.2 %/K. Operating voltage: 10 ... 30 V DC , ripple 10 %SS. No-load supply current: ≤ 15 mA (typ. 10 mA at UB = 24 V DC). Output type: 1 pulse output for echo run time, open collector NPN, short-circuit proof0 level (active): UOL ≤ 2 V, IOL ≤ 15 mA1 level (inactive): UOH = UB (pull-up R = 330 kOhm). Standard conformity: . StandardsEN IEC 60947-5-2:2020 IEC 60947-5-2:2019: . Standards: EN IEC 60947-5-2:2020 IEC 60947-5-2:2019. UL approval: cULus Listed, Class 2 Power Source. CCC approval: CCC approval / marking not required for products rated ≤36 V. Ambient temperature: 0 ... 50 °C (32 ... 122 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Connection type: Connector plug M12 x 1 , 4-pin. Degree of protection: IP30. Material: . HousingPBT: . Housing: PBT. Mass: 110 g. Dimensions: . Height31 mmWidth105 mmLength25 mm: . Height: 31 mm. Width: 105 mm. Length: 25 mm

Brand	Pepperl Fuchs
Lifecycle status	active
