V19-G-0,2M-PUR-ABG-V19-Y

Connecting cable, shielded. Connecting cable, M12 to M12, 8-pin, shielded, PUR cable. Number of pins: 8 + shield. Connection 1: socket. Construction type 1: straight. Threading 1: M12. Connection 2: p...

Connecting cable, shielded. Connecting cable, M12 to M12, 8-pin, shielded, PUR cable. Number of pins: 8 + shield. Connection 1: socket. Construction type 1: straight. Threading 1: M12. Connection 2: plug. Construction type 2: straight. Threading 2: M12. Operating voltage: max. 30 V AC/DC. Operating current: max. 2 A. Volume resistance: < 5 mΩ. Ambient temperature: -25 ... 80 °C (-13 ... 176 °F). Pollution degree: 3. Material: . ContactsCuZnContact surfaceNi/AuBodyTPU, black Zinc diecast, nickel-platedCablePURSlotted nutDiecast zincCore insulationPP: . Contacts: CuZn. Contact surface: Ni/Au. Body: TPU, black Zinc diecast, nickel-plated. Cable: PUR. Slotted nut: Diecast zinc. Core insulation: PP. Cable: extra-fine wire, flexible. Sheath diameter∅5.9 mmBending radius> 10 x cable diameter, movable installationColorblackCores8 x 0.25 mm2Conductor construction32 x 0.1 mm ∅Shieldgrid covering 85 %LengthL20 cm: . Sheath diameter: ∅5.9 mm. Bending radius: > 10 x cable diameter, movable installation. Color: black. Cores: 8 x 0.25 mm2. Conductor construction: 32 x 0.1 mm ∅. Shield: grid covering 85 %. Length: 20 cm. Mass: 73.05 g

Brand	Pepperl Fuchs
Lifecycle status	active
