V1S-G-0,5M-PUR-A-3T-1,5M-V23-G

Y connection cable. Y connection cable M23 plug straight A-coded 12-pin to 3x M12 plug straight A-coded 4-pin, 4x PUR cable black. Connector 1: . ConnectionplugConstruction typeM12StylestraightLocking...

Y connection cable. Y connection cable M23 plug straight A-coded 12-pin to 3x M12 plug straight A-coded 4-pin, 4x PUR cable black. Connector 1: . ConnectionplugConstruction typeM12StylestraightLockingscrew connectionNumber of pins4CodingA-coded: . Connection: plug. Construction type: M12. Style: straight. Locking: screw connection. Number of pins: 4. Coding: A-coded. Connector 2: . ConnectionplugConstruction typeM12StylestraightLockingscrew connectionNumber of pins4CodingA-coded: . Connection: plug. Construction type: M12. Style: straight. Locking: screw connection. Number of pins: 4. Coding: A-coded. Connector 3: . ConnectionplugConstruction typeM12StylestraightLockingscrew connectionNumber of pins4CodingA-coded: . Connection: plug. Construction type: M12. Style: straight. Locking: screw connection. Number of pins: 4. Coding: A-coded. Connector 4: . ConnectionplugConstruction typeM23StylestraightLockingscrew connectionNumber of pins12CodingA-coded: . Connection: plug. Construction type: M23. Style: straight. Locking: screw connection. Number of pins: 12. Coding: A-coded. Operating voltage: max. 48 V AC / 60 V DC. Operating current: max. 4 A. Degree of protection: EN 60529. Plug connection: connector M12 x 1 : IEC 61076-2-101. CCC approval: This product is not subject to authorization and therefore does not bear a CCC marking.. Maximum permissible operating voltagemax. 75 V AC/DC: . Maximum permissible operating voltage: max. 75 V AC/DC. Ambient temperature: . Plug connector-40 ... 90 °C (-40 ... 194 °F)Connector 4-40 ... 125 °C (-40 ... 257 °F)Cable, fixed installation-40 ... 80 °C (-40 ... 176 °F)Cable, flexing-25 ... 80 °C (-13 ... 176 °F): . Plug connector: -40 ... 90 °C (-40 ... 194 °F). Connector 4: -40 ... 125 °C (-40 ... 257 °F). Cable, fixed installation: -40 ... 80 °C (-40 ... 176 °F). Cable, flexing: -25 ... 80 °C (-13 ... 176 °F). Pollution degree: 2. Plug connector: . Tightening torque0.6 NmLoosening protectionavailableTool installationstraight knurlingMating cyclesmin. 100: . Tightening torque: 0.6 Nm. Loosening protection: available. Tool installation: straight knurling. Mating cycles: min. 100. Connector 4: . Tool installationstraight knurling , SW = 24 mm and SW = 27 mmMating cyclesmin. 50: . Tool installation: straight knurling , SW = 24 mm and SW = 27 mm. Mating cycles: min. 50. Degree of protection: IP67 / IP68 / IP69. Cable: according to IEC/EN 60228 (DIN VDE 0295) class 6. Sheath diameter∅8.8 mm / ∅4.8 mmBending radius> 5 x cable diameter, movable installationSheath colorblack (similar to RAL 9005)Cores10 x 0.34 mm2 4 x 0.34 mm2Core construction42 x 0.1 mm / 19 x 0.15 mm ∅LengthLL1 = 0.6 m L2 = 0.6 m L3 = 0.6 m L4 = 1.5 m: . Sheath diameter: ∅8.8 mm / ∅4.8 mm. Bending radius: > 5 x cable diameter, movable installation. Sheath color: black (similar to RAL 9005). Cores: 10 x 0.34 mm2 4 x 0.34 mm2. Core construction: 42 x 0.1 mm / 19 x 0.15 mm ∅. Length: L1 = 0.6 m L2 = 0.6 m L3 = 0.6 m L4 = 1.5 m. Mass: 38.6 g. Plug connector: . Screw connectionZinc diecast, nickel-platedBodyTPU, blackContact surfaceAuFlammabilityV-2: . Screw connection: Zinc diecast, nickel-plated. Body: TPU, black. Contact surface: Au. Flammability: V-2. Connector 4: . BodyZinc diecast, nickel-platedContact surfaceAu / Ni: . Body: Zinc diecast, nickel-plated. Contact surface: Au / Ni. Cable: . SheathingPUR based on polyetherCore insulationPPFlammabilityFT2: . Sheathing: PUR based on polyether. Core insulation: PP. Flammability: FT2

Brand	Pepperl Fuchs
Lifecycle status	active
