Pepperl Fuchs

V3-M8-500

Receptacles. 3-pin M8 receptacle. Connector 1: . ConnectionsocketConstruction typeM8StylestraightLockingscrew connectionNumber of pins3CodingA-coded: . Connection: socket. Construction type: M8. Style: straight. Locking: screw connection. Number of pins: 3. Coding: A-coded. Connector 2: . Connectioncable end: . Connection: cable end. Operating voltage: max. 48 V AC / 60 V DC. Operating current: max. 4 A. Volume resistance: < 3 mΩ. Degree of protection: EN 60529. Plug connection: connector M8 x 1 : IEC 61076-2-104. Flammability: IEC 60332-1-2. Halogen-free: IEC 60754-1. UL File Number: E191152. Ambient temperature: . Plug connector-25 ... 85 °C (-13 ... 185 °F)Cable, fixed installation-40 ... 105 °C (-40 ... 221 °F)Cable, flexing-10 ... 105 °C (14 ... 221 °F): . Plug connector: -25 ... 85 °C (-13 ... 185 °F). Cable, fixed installation: -40 ... 105 °C (-40 ... 221 °F). Cable, flexing: -10 ... 105 °C (14 ... 221 °F). Pollution degree: 3. Plug connector: . Tightening torque0.4 NmMating cyclesmin. 100: . Tightening torque: 0.4 Nm. Mating cycles: min. 100. Degree of protection: IP67. Connection: tinned copper single leads, ∅1.5 ±0.1 mm. Cable: . Number of cores3Core cross section0.25 mm2Cores colorCore 1: brown Core 3: blue Core 4: blackCore construction7 x 0.2 mm ∅ AWG 24LengthL500 mm: . Number of cores: 3. Core cross section: 0.25 mm2. Cores color: Core 1: brown Core 3: blue Core 4: black. Core construction: 7 x 0.2 mm ∅ AWG 24. Length: 500 mm. Installation: Front mounting M8 , tightening torque: 0.8 ... 1 Nm. Mass: 12 g. Halogen-free: yes. Plug connector: . Screw connectionbrass, nickel-platedSealFKMContact surfacegold plated (Au)FlammabilityHB: . Screw connection: brass, nickel-plated. Seal: FKM. Contact surface: gold plated (Au). Flammability: HB. Cable: . Core insulationPVC: . Core insulation: PVC. Scope of delivery: locknut not included

Brand	Pepperl Fuchs
Lifecycle status	active

Not currently in stock

Price on request

Request sourcing Ask a question
