V31-GM-5M-PUR-ABG-Y222310

Female connector. Female cordset, M8, 4-pin, PUR cable. Number of pins: 4 + shield. Connection 1: socket. Construction type 1: straight. Threading 1: M8. Connection 2: cable end. Operating voltage: ma...

Female connector. Female cordset, M8, 4-pin, PUR cable. Number of pins: 4 + shield. Connection 1: socket. Construction type 1: straight. Threading 1: M8. Connection 2: cable end. Operating voltage: max. 30 V DC. Test voltage: > 800 V eff AC. Operating current: max. 4 A. Volume resistance: ≤ 3 mΩ. Ambient temperature: -25 ... 85 °C (-13 ... 185 °F) cable, fixed installation: -30 ... 70 °C (-22 ... 158 °F). Pollution degree: 3. Degree of protection: IP67. Material: . ContactsCuSnContact surfaceAuBodyCuZn, nickel-platedCablePURCore insulationPP: . Contacts: CuSn. Contact surface: Au. Body: CuZn, nickel-plated. Cable: PUR. Core insulation: PP. Cable: fine-strand, flexible. Sheath diameter∅6,5 mmBending radius> 10 x cable diameter, movable installationColorblack molded finish (RAL 9005)Cores4 x 0.5 mm2Conductor construction28 x 0.15 mm ∅ShieldgridLengthL5 m: . Sheath diameter: ∅6,5 mm. Bending radius: > 10 x cable diameter, movable installation. Color: black molded finish (RAL 9005). Cores: 4 x 0.5 mm2. Conductor construction: 28 x 0.15 mm ∅. Shield: grid. Length: 5 m. Mass: 336 g

Brand	Pepperl Fuchs
Lifecycle status	active
