V31-GM-BK5M-PVC-U-PREH5-PNP

Female connector. Female cordset, M8, 4-pin, PVC cable. Number of pins: 4. Connection 1: socket. Construction type 1: straight. Threading 1: M8. Connection 2: plug. Construction type 2: straight. UL F...

Female connector. Female cordset, M8, 4-pin, PVC cable. Number of pins: 4. Connection 1: socket. Construction type 1: straight. Threading 1: M8. Connection 2: plug. Construction type 2: straight. UL File Number: E231213. Operating voltage: max. 30 V DC. Test voltage: > 1500 V eff AC. Operating current: max. 4 A. Volume resistance: < 5 mΩ. Standard conformity: . Degree of protectionEN 60529:2000StandardsIEC 61076-2-104:2008FlammabilityGrip: UL 94: . Degree of protection: EN 60529:2000. Standards: IEC 61076-2-104:2008. Flammability: Grip: UL 94. UL approval: AWM STYLE 2095 AWM I/II A/B 80°C 300V FT1 (cable). Ambient temperature: cable, fixed installation: -25 ... 80 °C (-13 ... 176 °F) cable, movable installation: -5 ... 80 °C (23 ... 176 °F). Pollution degree: 3. Contact elements: spring-loaded contact socket. Pin diameter: 1 mm. Degree of protection: IP67. Material: . ContactsCuSn / AuContact surfaceAuBodyTPU, blackCablePVCSlotted nutDiecast zincCore insulationPVC: . Contacts: CuSn / Au. Contact surface: Au. Body: TPU, black. Cable: PVC. Slotted nut: Diecast zinc. Core insulation: PVC. Cable: fine-strand, flexible. Sheath diameter∅ 4.3 mmBending radius> 15 x cable diameter, movable installation > 5 x cable diameter, fixed installationColorblackNumber of cores4Core cross section0.34 mm2Conductor construction19 x 0.15 mm ∅LengthL5 m: . Sheath diameter: ∅ 4.3 mm. Bending radius: > 15 x cable diameter, movable installation > 5 x cable diameter, fixed installation. Color: black. Number of cores: 4. Core cross section: 0.34 mm2. Conductor construction: 19 x 0.15 mm ∅. Length: 5 m. Mass: 179 g

Brand	Pepperl Fuchs
Lifecycle status	active
