VAN-KE2-2PE

AS-Interface power supply. AS-Interface power extender. UL File Number: E223772. LED PWR: AS-Interface voltage; LED green. LED U AS-i: AS-Interface voltage on the output is displayed in two stages:AS-...

AS-Interface power supply. AS-Interface power extender. UL File Number: E223772. LED PWR: AS-Interface voltage; LED green. LED U AS-i: AS-Interface voltage on the output is displayed in two stages:AS-Interface voltage > 28 V; LED greenAS-Interface voltage > 26 V; LED green. Insulation voltage: ≥ 500 V. Rated operating voltage: 30 V DC PELV. Number/Type: 2 AS-Interface circuits 1+2. Short-circuit protection/overload: 6 A self resetting fuse. Voltage: 29.5 ... 31.6 V DC. Rated current: 4 A at 30 V DC per ASi segment. Electromagnetic compatibility: . Directive 2014/30/EUEN 62026-2:2013: . Directive 2014/30/EU: EN 62026-2:2013. Electromagnetic compatibility: EN 61000-6-2, EN 61000-6-4. Degree of protection: EN 60529:2000. AS-Interface: EN 62026-2:2013. Ambient temperature: 0 ... 55 °C (32 ... 131 °F). Storage temperature: -25 ... 85 °C (-13 ... 185 °F). Degree of protection: IP20. Connection: removable terminals, terminal connection ≤ 2.5 mm2. Material: . HousingPA 6 GF30: . Housing: PA 6 GF30. Mass: 120 g. Dimensions: . Height99 mmWidth22.5 mmDepth92 mm: . Height: 99 mm. Width: 22.5 mm. Depth: 92 mm. Mounting: DIN mounting rail

Brand	Pepperl Fuchs
Lifecycle status	active
